Standard aluminum systems for window structures
Key features:
Installation depth, mm
45,5 mm
Maximum glazing thickness, mm.
4-8.2
Sealing contours, pieces of
EPDM 2 contours
Type of thermal insulation
No
Key features:
Installation depth, mm
76
Maximum glazing thickness, mm.
44, 46, 52, 54
Sealing contours, pieces of
EPDM 3 contours
Type of thermal insulation
Polyamides, Energy bar
Key features:
Installation depth, mm
50
Maximum glazing thickness, mm. from
4 to 26 mm
Sealing contours, pieces of
EPDM 2 contours
Type of thermal insulation
No
Key features:
Installation depth, mm
77
Maximum glazing thickness, mm.
from 32 to 54 mm
Sealing contours, pieces of
EPDM 3 contours
Type of thermal insulation
Polyamides, Energy bar
Standard aluminum systems for door structures
Key features:
Installation depth, mm
77
Maximum glazing thickness, mm. from
32 to 54 mm
Sealing contours, pieces of
EPDM 3 contours
Type of thermal insulation
Polyamides, Energy bar
Standard aluminum systems for sliding structures
Key features:
Installation depth, mm
2 rails 168.5 mm, 3 rails 258.5 mm
Maximum glazing thickness, mm.
from 32 to 50 mm
Sealing contours, pieces of
EPDM 2 contours
Type of thermal insulation
Polyamides, Energy bar
Key features:
Installation depth, mm
2 rails 136 mm, 3 rails 208 mm
Maximum glazing thickness, mm.
from 32 to 42 mm
Sealing contours, pieces of
EPDM 2 contours
Type of thermal insulation
Polyamides, Energy bar
Key features:
Mounting depth, mm
2 rails 45 mm, 3 rails 106 mm
Maximum glazing thickness, mm.
from 4.6 to 20 mm
Sealing contours, pcs
Felt 2 contours
Type of thermal insulation
No
Standard aluminum systems for facade systems
Key features:
Visible width of the system, mm
50
Maximum glazing thickness, mm.
from 4 to 60 mm
Sealing
EPDM
Type of thermal insulation
Polyamides, expanded polyethylene
Non-standard aluminum systems for window structures
Key features:
Installation depth, mm
85
Maximum glazing thickness, mm.
from 24 to 50 mm
Sealing contours, pieces of
EPDM 2 contours
Type of thermal insulation
Polyamides, Energy bar
Key features:
Installation depth, mm
65
Maximum glazing thickness, mm.
from 24 to 44 mm
Sealing contours, pieces of
EPDM 2 contours
Type of thermal insulation
Polyamides, Energy bar
Key features:
Installation depth, mm
115
Maximum glazing thickness, mm.
115
Sealing contours, pieces of
EPDM 2 contours
Type of thermal insulation
Polyamides, Energy bar
Key features:
Installation depth, mm
50
Maximum glazing thickness, mm.
from 4 to 28 mm
Sealing contours, pieces of
EPDM 2 contours
Type of thermal insulation
No
Non-standard systems for door structures
Key features:
Installation depth, mm
50
Maximum glazing thickness, mm.
from 4 to 28 mm
Sealing contours, pieces of
EPDM 2 contours
Type of thermal insulation
Polyamides
Нестандартні алюмінієві системи для розсувних конструкцій
Key features:
Mounting depth, mm
2 rails 92 mm, 3 rails 143 mm
Maximum glazing thickness, mm.
from 4 to 24 mm
Sealing contours, pcs
Felt 2 contours
Type of thermal insulation
No
Key features:
Installation depth, mm
164
Maximum glazing thickness, mm.
46
Sealing contours, pcs.
EPDM + Felt 3 contours
Type of thermal insulation
Polyamides, Energy bar
Non-standard aluminum systems for sliding structures
Key features:
Visible width of the system, mm
50
Maximum glazing thickness, mm.
from 4 to 60 mm
Sealing
EPDM
Type of thermal insulation
Polyamides, expanded polyethylene
Key features:
Visible width of the system, mm
55
Maximum glazing thickness, mm.
from 4 to 60 mm
Sealing
EPDM
Type of thermal insulation
Polyamides, expanded polyethylene
Non-standard systems for glass railings
Key features:
Maximum height, m
1.6
The maximum length of the structure, m
is unlimited
The type of glazing
is tempered glass
Glass thickness
12+12, 10+10, 8+8, 6+6, 5+5
