EKIPAZH AluLight WS142
EKIPAZH AluLight WS142 is a thermal lift-and-slide system designed to implement modern architectural solutions with large translucent surfaces.
The system is designed for both private homes and properties with high demands on energy efficiency, comfort, and design.
Advantages
- The design allows for the creation of large glass areas while minimizing the visible profile width to maximize natural light.
- High resistance to deformation, moisture, and temperature fluctuations is essential for the durability of large structures.
- The system provides high-quality sound insulation and airtightness thanks to a sophisticated sealing system.
- Designed for private homes, terraces, and commercial properties where the aesthetic appeal of an open space must be combined with a comfortable indoor climate.
- Supports the installation of double-glazed windows up to 44 mm thick, ensuring high energy efficiency.
- The lift-and-slide mechanism provides smooth, reliable, and comfortable opening.
Features:
- Mounting width, mm: 142 - 218
- Filling width, mm: 44
- System type: warm
- Max. chair width, mm: 2400
- Maximum sash height, mm: 3000
- Number of movable sashes: 2-6
- Possibility of painting: yes
- Thermal resistance coefficient W/m2K: 2.86
- Maximum sash dimensions, mm: 2400x2600
- Sash weight: up to 400 kg
DESIGN SOLUTIONS
RAL 1000
RAL 1007
RAL 1026
RAL 2005
RAL 3000
RAL 3005
RAL 3022
RAL 4001
RAL 4006
RAL 5000
RAL 5005
RAL 5013
RAL 6000
RAL 6005
RAL 6027
RAL 7000
RAL 7011
RAL 7021
RAL 7035
RAL 8000
RAL 8001
RAL 8014
RAL 9002
RAL 9005
RAL 9018
RAL 9023
